Thermophysical boundary conditions

Collaboration diagram for Thermophysical boundary conditions:

## Modules | |

Thermo baffle boundary conditions | |

## Classes | |

class | thermalBaffleFvPatchScalarField |

This boundary condition provides a coupled temperature condition between multiple mesh regions. More... | |

class | energyJumpFvPatchScalarField |

This boundary condition provides an energy jump condition across a pair of coupled patches. It is not applied directly, but is employed on-the-fly when converting temperature boundary conditions into energy. More... | |

class | energyJumpAMIFvPatchScalarField |

This boundary condition provides an energy jump condition across a pair of coupled patches with an arbitrary mesh interface (AMI). It is not applied directly, but is employed on-the-fly when converting temperature boundary conditions into energy. More... | |

class | fixedEnergyFvPatchScalarField |

This boundary condition provides a fixed condition for internal energy. More... | |

class | gradientEnergyFvPatchScalarField |

This boundary condition provides a gradient condition for internal energy, where the gradient is calculated using: More... | |

class | mixedEnergyFvPatchScalarField |

This boundary condition provides a mixed condition for internal energy. More... | |

class | greyDiffusiveRadiationMixedFvPatchScalarField |

This boundary condition provides a grey-diffuse condition for radiation intensity, `I` , for use with the finite-volume discrete-ordinates model (fvDOM), in which the radiation temperature is retrieved from the temperature field boundary condition. More... | |

class | greyDiffusiveViewFactorFixedValueFvPatchScalarField |

This boundary condition provides a grey-diffuse condition for radiative heat flux, `Qr` , for use with the view factor model. More... | |

class | MarshakRadiationFvPatchScalarField |

A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G) More... | |

class | MarshakRadiationFixedTemperatureFvPatchScalarField |

A 'mixed' boundary condition that implements a Marshak condition for the incident radiation field (usually written as G) More... | |

class | wideBandDiffusiveRadiationMixedFvPatchScalarField |

This boundary condition provides a wide-band, diffusive radiation condition, where the patch temperature is specified. More... | |

class | externalWallHeatFluxTemperatureFvPatchScalarField |

This boundary condition supplies a heat flux condition for temperature on an external wall. Optional thin thermal layer resistances can be specified through thicknessLayers and kappaLayers entries for the fixed heat transfer coefficient mode. More... | |

class | thermalBaffle1DFvPatchScalarField< solidType > |

This BC solves a steady 1D thermal baffle. More... | |

class | wallHeatTransferFvPatchScalarField |

This boundary condition provides an enthalpy condition for wall heat transfer. More... | |

This group contains thermophysical model boundary conditions
